Tech Specs
Technical Information
Diagonal Viewing Size
23.8"
Preset Display Area (H x V)
527.04 mm x 296.46 mm
20.75" x 11.67"
Area 156246.28 mm2 (242.18 inches2)
Panel Type
In-Plane Switching (IPS) technology
Display Screen Coating
Antiglare with hard-coating 3H
Maximum Preset Resolution
1920 x 1080
Refresh rate
100 Hz
Viewing Angle
178° vertical / 178° horizontal
Pixel Pitch
0.2745 mm x 0.2745 mm
Pixel Per Inch (PPI)
93
Contrast Ratio
1500: 1 (typical)
Aspect Ratio
16:9
Backlight Technology
LED edgelight system
Brightness
250 cd/m2 (typical)
Response Time
8 ms (Normal mode)
5 ms (Fast mode)
4 ms (Extreme mode)
Color Support
16.7 million colors
Color Gamut (typical)
99% sRGB (typical) (CIE1931)
TUV Eye Comfort
Yes, 4 Star
Ficker Free
Yes
Connectivity
2 x HDMI (HDCP 1.4) ( Supports up to FHD 1920 x 1080 100Hz, as per specified in HDMI1.4)
Adjustability
Tilt
Tilt
-5°/+21°
Dell Display Manager Compatibility
Yes with Easy Arrange
Voltage Required
100 VAC to 240 VAC/50 Hz or 60 Hz ± 3 Hz/1.5 A
Power Consumption
0.3 W (Off Mode)
0.4 W (Standby Mode)
14.5 W (On Mode)
42 W (Max)
13.0 W (Pon)
41.1 kWh (TEC)
Audio Output
Integrated 2 x 5W speakers
Security
Security-lock slot (for Kensington locks, sold separately)
Compliant Standards
RoHS-compliant
BFR/PVC reduce monitor (The circuit boards are made from BFR/PVC-free laminates.)
Arsenic-free glass and Mercury-free for the panel only
ENERGY STAR certified monitor
Flat Panel Mount Interface
VESA (100 mm)
Temperature Range
Operating: 0° to 40°C (32° to 104°F)
Non-operating: -20° to 60° (-4° to 140° F)
Humidity Range
Operating: 10% to 80% (non-condensing)
Non-Operating:5% to 90% (non-condensing)
Altitude
Operating: 5,000 m (16,400 ft) max
Non-Operating: 12,192 m (40,000 ft) max
What's Included
Cables Included
-
1 x Power cable
-
1 x HDMI cable
Physical Characteristics
Height with stand (Compressed ~ Extended)
16.21 in
Width with stand
21.17 in
Depth with stand
6.42 in
Height without stand
12.35 in
Width without stand
21.17 in
Depth without stand
2.32 in
Weight (panel only - for VESA mount)
7.25 lb
Weight (with packaging)
13.05 lb
Warranty
Specifications - Service / Support Details
WW - 3-Year Advanced Exchange Service and Premium Panel Exchange, US/Canada - 1-Year Advanced Exchange Service and Premium Panel Exchange
